Product Description

Name: UFO High Bay Light

Model No: NK-HBW-250W

Certificated by: ICON ICON

LED by:   philips

Powered by: mw

Share this product:

chat button

Product Details

Specifications
Item No.  NK-HBW-250W Lamp Power  250 W
LED luminous efficiency 140~160 lm/W Equivalent 750 W  high pressure sodium lamp
Lamp Rated luminous efficiency 140 lm/W Lamp Total Flux(Tj=60℃,Ta=25℃) 35000 lm
Input Voltage   AC100–277 V Frequency Range   47—63Hz
Lamp Efficiency   >93% Total Harmonic Distortion (THD)   <15%
Power Factor (PF)   >0.95 Color Rendering Index (CRI)   >80
Beam Angle   60° , 120° Color Temperature   3000k—7000K
Waterproof  IP65 Warranty 3–5 Years
Light Distribution Curve   Rectangular Beam Lifespan >50,000hrs
Working Temperature   -30℃ ~ +50℃ Lamp Body and Lampshade Material   Aluminum Alloy and PMMA
Lamp Size ¢350X190mm Net weight 5.5 kg
Application place Commercial lighting, industrial lighting, warehouses, freight terminals, stadiums, building facades,
Notes Dimmable or non dimmable , Body sensor dimming, sensor switch,  Ceiling Mount, Suspend ,
Parameter

highbay-structure ufo 120w led high bay light ufo high bay light

Application

application-1 application

Download Data

Send Us Email

Want to ask questions, suggestions or business advice? We would be happy to contact you.

send email

Recommended Products

Know more about LED explosion proof light
View more »

Product Description

Name: LED Explosion Proof Light

Model No: NK-EPW3-150W

Certificated by: ICON ICON

LED by:  BRIDGEX EPISTAR

Powered by: mwOR High Efficiency Driver

Share this product:

chat button

Product Details

Specifications
Lamp Rated luminous efficiency 110 lm/W Output Voltage 42V
LED luminous efficiency 140~160 lm/W Output Current 11000mA
Lamp Total Flux(Tj=60,Ta=25) 55297 lm Lamp Power 502.7W
Lamp’s Efficiency >93% LED Power 493W
Power Factor >0.98 THD <15%
Input Voltage AC90-305V Warranty 5Years
Beam Lighting Angle 100°,90°,60°,45°,25° Guard Level IP65
Light Distribution Curve Rectangular Beam Lifespan >50,000hrs
Working Temperature -40℃ ~ +50℃ CRI >80
Parameter

NK-EPW3-150W (5)

Application

applicationapplication-1
